The NTW Series manual torque wrenches provide accurate and consistent torque control for a wide range of industrial bolting and maintenance applications, with torque capacities ranging from 12 to 1000 Nm (10 to 730 lbf.ft).
Engineered for accuracy of ±3% in accordance with ISO 6789-1:2017, the range combines robust construction with dual-scale torque readings in Nm and lbf.ft and an easy-to-adjust micrometer scale for precise torque setting. The wrenches feature push-through ratchet mechanisms for clockwise and counterclockwise operation, and incorporate a secure adjustment lock to prevent accidental changes to the preset torque.
Available with a range of square drive sizes, including interchangeable ¾″ and 1″ drives on selected models, the NTW Series offers dependable performance for industrial maintenance, machinery assembly, equipment servicing and other demanding bolting operations.
- Torque capacities from 12 to 1000 Nm (10 to 730 lbf.ft)
- Square drive sizes from 3 ⁄8” to 1”
- Dual scale torque reading in Nm & lbf.ft
- Bi-directional push-through ratchet with a narrow engagement angle for confined spaces
- Repeatable accuracy of ±3% in accordance with ISO 6789-1:2017
- Supplied with individual Declaration of Conformance
- Alignment pin safeguarding feature physically prevents the use of incompatible attachments, reducing the risk of improper setup (for NTW600, NTW800 and NTW1000 models only)
- NTW600, NTW800 and NTW1000 models can be split into two parts for a smaller, easier-to-transport package
